Old Tannehill Rd over Coal Creek
In service 1927–2011 (84 yrs)
Closed to traffic
Through Truss
Old Tannehill Rd over Coal Creek
Through Truss
Built 1927
280.00 ft
Built
1927
Type
Through Truss
Style
Pratt
Length
280.00 ft
Main span
120.00 ft
Spans
3
Visits
1
Identity & location
- NBI Number
- 019350000000000
- Structure Number
- 61N4040E1402000
- Carries
- Tannehill Rd
- Crosses
- Coal Creek
- Year Built
- 1927
- Year Closed
- 2011
- Year Replaced
- 2011
Structure
1 × 120.00ft Pratt Through Truss span (6 panels), 2 × 80ft Camelback Pony Truss approach spans, 280.00ft overall
- Bridge Type
- Through Truss
- Main Span Style
- Pratt
- Approach Span Style
- Camelback
- Connections
- Riveted
- Overall Length
- 280.00 ft
- Main Span Length
- 120.00 ft
- Main Spans
- 1
- Approach Spans
- 2
- Main Span Panels
- 6
Span diagram
Direction: North to South
80.00'
120.00'
80.00'
| # | Type | Style | Length | Panels | Role |
|---|---|---|---|---|---|
| 1 | Pony Truss | Camelback | 80.00 ft | 5 | Approach |
| 2 | Through Truss | Pratt | 120.00 ft | 6 | Main |
| 3 | Pony Truss | Camelback | 80.00 ft | 5 | Approach |
